SEWING PEDALS

We take individuality and perfect-fit ergonomics especially seriously. This is also clear from our broad range of sewing pedals. Our spectrum ranges from economical standard pedals to all kinds of double pedals– all the way to innovative ERGONOMIC pedals. These offer unique advantages for working when standing up. KESSLER also offers an ergonomic workstation mat.

SEWING PEDALS: STANDARD PEDALS

Sewing pedals: Large pedal plate model "L"

  • Width of the sewing pedal approx. 265 mm, depth of the sewing pedal approx. 240 mm
  • With welded bracket
  • With chain bracket for actuator
  • Article number: 11-00030

Sewing padels: Large sewing pedal model „LF“

  • Width of the sewing pedal approx. 265 mm, depth of the sewing pedal approx. 240 mm
  • With welded bracket
  • With return spring
  • With chain bracket for actuator
  • Article number: 11-00166

Sewing pedals: Small sewing pedal model „L“

  • Width of the sewing pedal approx. 135 mm, depth of the sewing pedal approx. 240 mm
  • With welded bracket
  • With chain bracket for actuator
  • Article number: 11-00031

Sewing pedals: Small pedal model „LF“

  • Width of the sewing pedal approx. 135 mm, depth of the sewing pedal approx. 240 mm
  • With welded bracket and chain bracket for actuator
  • With return spring and adjusting screw
  • Article number: 11-00035

Sewing pedals: Pedal model „P-DK“

  • Width of the sewing pedal approx. 500 mm, depth of the sewing pedal approx. 310 mm
  • With anti-slip rubber pad
  • With bracket
  • With chain bracket for actuator
  • Article number: 11-00056

Sewing pedals: Pedal system model „P-DKS“

  • Pedal system for stand alone use
  • Width of the sewing pedal approx. 500 mm, depth approx. 310 mm
  • With anti-slip rubber pad
  • Base plate with 4 rubber feet
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • With chain bracket for actuator
  • Article number: 11-00167

Sewing pedals: Double pedal model „K-4“

  • Double pedal consisting of small and large pedal plate
  • Delivery with galvanized axle 620 mm long, pull lever 140 mm long with clamp, distance sleeve, bracket and chain bracket
  • Standard axle length: 620 mm, further axle lengths: 860 mm, 1,000 mm
  • Small pedal plate welded on axle
  • Large pedal plate: actuation by means of chain bracket
  • Article number: 11-00052

Sewing pedals: Pedal system model „K-15“

  • Pedal plate on galvanized axle 860 mm long welded, pull lever 210 mm long with clamp, as well as 3 brackets and chain bracket for actuator
  • Article number: 11-00330

Sewing pedals: Pedal system model „K-16“

  • Pedal plate on galvanized axle 860 mm long welded, pull lever 210 mm long with clamp, as well as 3 angled brackets and chain bracket for actuator
  • Fits KES-B-Ex, KES-2000 and KES-2100 with lateral extension
  • Article number: 11-00528

Sewing pedals: Pedal system model „K-18“ universal

  • Rocker pedal assembly consisting of base plate (445 x 300 mm), pedal and universal actuator holder
  • For standalone use
  • With chain bracket for actuator
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • Article number: 11-00245

Sewing pedals: Pedal system model "K-20"

  • Pedal plate for fixing on the treadle bar or for stand alone use
  • Base frame with 4 rubber feet
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho  Hsing, JUKI, Quick,  Typical. Further on request
  • With chain bracket for actuator
  • Article number: 11-00129

Sewing pedals: Pedal system model „K-30“

  • Height-adjustable treadle for increased working comfort and ergonomics
  • For stand alone use, for sit-down and stand-up workstations
  • Height adjustment range from approx. 100 mm to 285 mm
  • With 4 rubber feet
  • With integrated drill holes for mounting the actuator. Suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • With chain bracket for actuator
  • Article number: 11-00126

SEWING PEDALS: STANDARD PEDALS



Sewing pedals: Ergo Pedal model „K-40“

  • Pedal system for stand-up working with high standing comfort thanks to ergonomic workstation mat
  • Ergonomic and user-friendly design of pedal, which can be operated on both the left and the right side. This enables the user to vary his/her posture during working, thus preventing postural damage.
  • Dimensions of base plate: approx. 695 mm deep x 665 mm wide
  • Weight: approx. 9.5 kg
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • Article number „K-40-DA“ (Dürkopp Adler): 11-00544-35
  • Article number „K-40-EB 301“ (Efka EB 301): 11-00124-35
  • Article number „K-40-EB 401“ (Efka EB 401): 11-00144-35
  • Article number „K-40-HO“ (Ho Hsing): 11-00547-35
  • Article number “I60”, “HVP70” or GM60 „K-40-JUKI-SC920-M92“ (Juki): 11-00546-35
  • Article number „K-40-Q“ (Quick): 11-00125-35
  • Article number „K-40-T“ (Typical): 11-00123-35

Sewing pedals: Ergo Pedal model „K-42“

  • Ergonomic and user-friendly design of pedal, which can be operated on both the left and the right side. This enables the user to vary his/her posture during working, thus preventing postural damage.
  • Suitable for standing and sitting work.
  • Dimensions of base plate: approx. 500 mm deep x 400 mm wide
  • Weight: 9.8 kg
  • Surface: powder-coated
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • Article number „K-42-DA“ (Dürkopp Adler): 11-01924-35
  • Article number „K-42-EB 301“ (Efka EB 301): 11-01921-35
  • Article number „K-42-EB 401“ (Efka EB 401): 11-01922-35
  • Article number „K-42-HO“, „I60“, „HVP70“ or GM60“ (Ho Hsing): 11-01927-35
  • Article number „K-42-JUKI-SC920-M92“ (Juki): 11-01926-35
  • Article number „K-42-Q“ (Quick): 11-01923-35
  • Article number „K-42-T“ (Typical): 11-01920-35

Sewing pedals: Ergo Pedal model „K-44“

  • Ergonomic and user-friendly design of pedal, which can be operated on both the left and the right side. This enables the user to vary his/her posture during working, thus preventing postural damage.
  • Suitable for standing and sitting work.
  • Dimensions of base plate: approx. 250 mm deep x 400 mm wide
  • Weight: approx. 5.3 kg
  • Surface: powder-coated
  • Mounting for actuator, suitable for: Dürkopp Adler, Efka, Ho Hsing, JUKI, Quick, Typical. Further on request
  • Article number „K-44-DA“ (Dürkopp Adler): 11-01904-35
  • Article number „K-44-EB 301“ (Efka EB 301): 11-01901-35
  • Article number „K-44-EB 401“ (Efka EB 401): 11-01902-35
  • Article number „K-44-HO“, “I60”, “HVP70”, “GM60” (Ho Hsing): 11-01907-35
  • Article number „K-44-JUKI-SC920-M92“ (Juki): 11-01906-35
  • Article number „K-44-Q“ (Quick): 11-01903-35
  • Article number „K-44-T“ (Typical): 11-01900-35

SEWING PEDALS: ERGONOMIC PEDALS

With the "ERGONOMIC" pedal system, KESSLER offers unique advantages for stand-up operation. Thanks to the clever distribution of speed, foot lift and thread trimming across two pressure sensors, the user can stand with equal load on both legs. The great benefit of this even distribution of weight across two legs is effective prevention of postural damage and fatigue symptoms.

Specification of sewing speed as well as activation of the foot lift or thread trimming is effected only by slight weight shifting on the sensor elements. This efficiently prevents faulty posture and any resulting health damage.

METHOD OF FUNCTIONING

Specification of the sewing speed as well as activation of the foot lift or the thread trimming is effected only by slight weight shifting on the sensor elements. This efficiently prevents faulty posture and any resulting health damage.
The sensitivity of the sensor elements can be easily adjusted by all users via potentiometers. The required reliability is guaranteed by a safety lock. During sewing, the functions "FL" and "FA" cannot be controlled. For control, the speed setting needs to be set to "0". Malfunctions during sewing due to "FL" / "FA" are thus ruled out.
The sensor signals are evaluated via an electronic interface. This can be inserted directly into the socket for the external actuator of the motor control, without further modification. An actuator is thus completely dispensed with. The pedal system is available for drives by the following manufacturers: Dürkopp Adler, Efka and Quick.

Sensor Elements Graphics

Sewing pedals: Pedal system model "ERGONOMIC I"

  • Base plate integrated with both sensors
  • Dimensions of base plate: 500 x 500 mm
  • Weight: approx. 8 kg
  • Article number „ DA-Classic-1“ (Dürkopp Adler with 9-pin SUB-D plug): 11-01020
  • Article number „E-230-1“ (Efka with 5-pin DIN plug and power supply 230 V/50 Hz): 11-01000
  • Article number „E-Kompakt-1“ (Efka with 9-pin SUB-D plug): 11-01010
  • Article number „Q-230-1“ (Quick with 7-pin DIN plug): 11-01003
  • Article number „Q-Mini-1 (ECO-DRIVE-2 P 40 ED)“ (Quick with 9-pin SUB-D plug and power supply 230 V/50 Hz): 11-01013

Sewing pedals: Pedal system model "ERGONOMIC II"

Two individual small pedals, each with one sensor, enable the user to position the pedals individually. It is also possible to steer the sewing machine with the elbows, for example, instead of with the feet – so physically challenged people can also use a sewing machine.

  • Dimensions of base plate: 190 x 155 m
  • Weight: approx. 2.25 kg
  • Article number „DA-Classic-2“ (Dürkopp Adler with 9-pin SUB-D plug): 11-01030
  • Article number „E-230-2“ (Efka with 5-pin DIN plug and power supply 230 V/50 Hz): 11-01040
  • Article number „E –Kompakt–2“ (Efka with 9-pin SUB-D plug): 11-01050
  • Article number „Q-230-2“ (Quick with 7-pin DIN plug): 11-01043
  • Article number „Q-Mini-2 (ECO-DRIVE-2 P 40 ED)“ (Quick with 9-pin SUB-D plug): 11-01014

Sewing pedals: Pedal system model "ERGONOMIC III"

  • This pedal system is the result of continuous further development. It combines a comfortable standing area with the features of the sensor pedal, proven for decades.
  • With polyurethane integral foam pad to improve comfort and ergonomics
  • Dimensions of base plate: 660 x 490 mm
  • Weight: approx. 10 kg
  • Article number „DA-Classic-3“ (Dürkopp Adler DAC-3 with 9-pin SUB-D plug): 11-01070
  • Article number „E-230-3“ (Efka with 5-pin DIN plug and power supply 230 V/50 Hz): 11-01065
  • Article number „E-Kompakt-3“ (Efka with 9-pin SUB-D plug): 11-01060
  • Article number „Q-230-3“ (Quick with 7-pin DIN plug): 11-01075
  • Article number „Q-Mini-3 („ECO-DRIVE-2 P 40 ED)“ (Quick with 9-pin SUB-D plug): 11-01080

Workstation mat "ERGONOMIC"

Working on overly hard industrial floors for long periods can overload the joints and musculature. Our workstation mat provides suitable damping - for painless, effective and concentrated work. In addition, the special anti-slip coating increases work safety.

  • Article number 940 x 640 mm: 11-00853
  • Article number 470 x 640 mm: 11-00883
  • Other dimensions on request
